Name: GW Instek PPH [PPH-1503] Single-Channel Dual Range Programmable DC Power Supply, 15V/3A, 9V/5A, 45W
Brand: GW Instek
Price: 51223200 USD
Availability: OutOfStock

GW Instek PPH [PPH-1503] Single-Channel Dual Range Programmable DC Power Supply, 15V/3A, 9V/5A, 45W

0 reviews • Write a review

from

Rp.51,223,2210

Brand: GW Instek
Part Number: PPH-1503
Availability: 4 - 6 WEEKS
Last Updated: 23 Apr 2026

GW Instek

Qty

Add to Cart

Add to Wish List Compare this Product

Description

The GW Instek PPH-1503 is a 45W, high-precision programmable linear DC power supply designed for low-power devices, featuring dual-range output (0–15V/0–3A or 0–9V/0–5A) and fast transient recovery (< 40µs). It offers high resolution (1mV/0.1µA), built-in DVM, current sinking (up to 2A), and USB/LAN/GPIB interfaces, making it ideal for testing portable device power consumption. The GW Instek PPH-1503 is a 45W, high-precision programmable linear DC power supply designed for applications requiring fast transient recovery, low-current measurement, and sink current capability. Key applications include testing mobile devices, consumer electronics, and components, featuring 1mV/0.1µA resolution and built-in DVM.

PPH-1503 is a high-speed and high-precision DC Power Supply with dual range of 15V/3A or 9V/5A. PPH-1503 is exclusively designed to meet low power consumption requirements and users’ great demands of accuracy, speed and resolution of both voltage and current. Circuits are designed with swift response capability to provide a stable voltage output while experiencing load changes. For example, when switching cellular phone from standby to talk mode, the current consumption will be dramatically changed within milliseconds. When load current exceeded current limit, two operational modes: Limit and Trip can be selected. Under Limit mode, PPH-1503 will automatically switch to constant current (CC) mode. Under Trip mode, voltage output will automatically turn off. PPH-1503 is designed to provide prompt response to the current change for recovering the output voltage at a minimum variation. The high sampling rate allows fast readback in voltage and current measurement to expedite products’ testing speed, which is able to increase the test throughput of production. Sink function can be used to test the battery charger of portable devices. The high precision performance of PPH-1503 provides the measurement capability in low power consumption level. One built-in DVM (Digital Volt-Meter) with input ports is designed to measure any point on DUT while PPH-1503 is outputting voltage and current. Besides, two ports are located on the front and rear panel which users can only select one to perform tests based upon their connection convenience. PPH-1503 is an ideal power source for production lines, R&D laboratories, device inspection, maintenance centers or facilities with the requirements of a swift and precise power supply with DVM. In the testing of assembling LED backlight module into products such as TV, Monitor, Tablet and NB, the minimum requirement of current resolution should be at least four digits. Different sized LED backlights require different current consumption. Most LED backlights are 150mA, in which, ordinary power supplies could not provide the above-mentioned high current resolution of four digits. However, PPH-1503 provides 0.1mA (equivalent to 4 4/5 digits) current resolution under 5A setting as well as rapid transmission time of both measurement and commands to fully satisfy the testing requirement of current resolution so as to raise the production capacity. To achieve high working voltage requirements, PPH-1503 can be in series with GW Instek GPR-H series power supplies to conduct the testing of high voltage products.

GW Instek PPH [PPH-1503] Single-Channel Dual Range Programmable DC Power Supply, 15V/3A, 9V/5A, 45W
