Name: Siglent SDS2000X Series [SDS2202X] 200MHz, 2-Ch Digital Oscilloscope
Brand: PT. Indomultimeter Test Instrument
Availability: OutOfStock
Rating: 5 (1 reviews)

Siglent SDS2000X Series [SDS2202X] 200MHz, 2-Ch Digital Oscilloscope

0 ulasan • Tulis ulasan

from

Rp.32.500.000

Sebelum Pajak: Rp.32.500.000

Brand: Siglent
Suku Cadang: SDS2202X
Ketersediaan: 4 - 6 MINGGU
Update Terakhir: 18 Dec 2019

Siglent

Jumlah

+ Keranjang

Tambah ke Favorit Bandingkan produk ini

Tags/penandaan: Fluke , Basic , Battery , Analyzer

Description

The Siglent’s SDS2202X is a 200MHz 2-channel Digital Oscilloscope that improves on its predecessor the SDS2202, with a faster screen refresh rate (140,000 wfm/s normal mode, up to 500,000 wfm/s sequence mode), much bigger waveform memory, faster sampling (2GSa/s) and simpler operation. Most commonly used functions can now be accessed with a user-friendly one-button design. The SDS2202X features a new generation of SPO “Super Phosphor” technology. It has an innovative digital trigger system with high sensitivity and low jitter. As well as a 256-level intensity grading display function, it includes but a color temperature display mode to show even more signal information. The trigger system supports multiple powerful triggering modes including serial bus triggering. History waveform recording and sequence acquisition allow for extended waveform records to be captured, stored, and analyzed. Also included is an impressive array of measurement and math capabilities.

Options to add to the SDS2202X’s functionality and usefulness include a 25 MHz arbitrary waveform generator, 16 digital channels (MSO), as well as serial decoding.

Features:

Bandwidth: 200 MHz
Channels: 2 CH
Real time sampling rate: 2 GSa/s
Waveform capture rate up to 140,000 wfm/s (normal mode), and 500,000 wfm/s (sequence mode)
Supports 256-level intensity grading and color temperature display
Record length up to 140 Mpts
Digital trigger system
Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern and Video (HDTV supported)
Serial bus triggering and decoder, supports protocols IIC, SPI, UART, RS232, CAN and LIN (Optional)
Low background noise, supports 1 mV/div to 10 V/div voltage scales
10 types of one-button shortcuts, including Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist,

Clear Sweeps, Zoom and Print

Segmented acquisition (Sequence) mode divides the maximum record length into multiple segments (up to

80,000), according to trigger conditions set by the user. The resulting acquisition has a very small dead time
segment.

History waveform record (History) function, the maximumr ecorded waveform length is 80,000 frames
Automatic measurement function on 37 parameters, supports statistics, Gating measurements, Math

measurements, History measurements and Ref measurements

Math function (FFT, addition, subtraction, multiplication, division, integration, differential, square root)
High Speed hardware based Pass/ Fail function
16 Digital channels (MSO option), Maximum waveform capture rate up to 500 MSa/s, Record length up to 140

Mpt/CH

25 MHz function/arbitrary waveform generator, built-in 10 types of waveforms (option)
Large 8 inch TFT-LCD display with 800 * 480 resolution
Multiple interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11), Pass/Fail, Trigger Out
Supports SCPI remote control commands
Supports Multi-language display and embedded online Help
