AEMC 6550 [2130.31] Megohmmeter (Graphical, Analog Bargraph, Backlight, Alarm, Timer)

Name: AEMC 6550 [2130.31] Megohmmeter (Graphical, Analog Bargraph, Backlight, Alarm, Timer)
Brand: PT. Indomultimeter Test Instrument
Availability: OutOfStock
Rating: 5 (1 reviews)

0 ulasan • Tulis ulasan

from

Rp.163.364.000

Sebelum Pajak: Rp.163.364.000

Brand: AEMC
Suku Cadang: 2130.31
Ketersediaan: 4 - 6 MINGGU
Update Terakhir: 19 Mar 2024

AEMC

Jumlah

+ Keranjang

Tambah ke Favorit Bandingkan produk ini

Tags/penandaan: Additel , Digital , Pressure , Calibrators

Description

AEMC 6550 [2130.31] Digital Megohmmeter w/Graphical, Analog Bargraph, Backlight, Alarm, Timer, 500V, 1000V, 2500V, 5000V, 10kV, Ramp, StepV, Variable, Auto DAR/PI/DD, USB, w/DataView Software. The AEMC 6550 10,000V Megohmmeter is a high-end portable Megohmmeter intended for the measurement of a wide varity of electrical insulation resistance values on cables and devices operating at high voltage. The AEMC 6550 Megohmmeter is the only fully automated 10,000V graphical insulation tester. Additionally, the AEMC 6550 Megohmmeter provides insulation measurements up to 30,000GΩ (30TΩ). Test results include DAR, PI, DD, ΔR, Capacitance, Leakage Current, as well as programmable temperature correction of resistance readings. The AEMC 6550 is packaged in a rugged case that is IP54 when closed. Test results and configuration information is provided on a graphical LCD screen as well as exportable through the use of DataView software provided. This megohmmeter can operate on battery or AC power while testing. The AEMC 6550 also offers the ability to program up to three step voltage profiles (from 40 to 10,000), each containing up to ten steps. Also, the AEMC 6550 has ramp profiles and three programmable test voltages in addition to the standard fixed voltages of 500, 1000, 2500, 5000 and 10,000V.
