Name: Teledyne LeCroy T3DSO2000 Series [T3DSO2202] 200 MHz 2 Channel Digital Oscilloscope
Brand: PT. Indomultimeter Test Instrument
Availability: OutOfStock
Rating: 5 (1 reviews)

Teledyne LeCroy T3DSO2000 Series [T3DSO2202] 200 MHz 2 Channel Digital Oscilloscope

0 reviews • Write a review

from

Rp.49,250,0000

Brand: Teledyne
Part Number: T3DSO2202
Availability: 3 - 4 WEEKS
Last Updated: 12 Jan 2024

Teledyne

Qty

Add to Cart

Add to Wish List Compare this Product

Tags: Fluke , Basic , Battery , Analyzer

Description

The Teledyne LeCroy T3DSO2202 2-channel 200MHz Oscilloscope employs a new generation of high speed display technology that provides excellent signal clarity, fidelity and performance. Providing a real-time sampling rate up to 2GSa/s this scope’s system noise-floor is also lower than similar products in the industry. The T3DSO2202 comes with a minimum vertical input range of 1mV/div, an innovative digital trigger system with high sensitivity and low jitter, and a new generation of high speed display technology that delivers a waveform capture rate up to 140,000wfm/s (normal mode), and 500,000wfm/s (sequence mode). The T3DSO2000 series also employs a 256-level intensity grading display function and a color temperature display mode which complement the high speed update rate. For ease-of-use, the most commonly used functions can be accessed with its user-friendly front panel design.

Teledyne Test Tools latest oscilloscope offering supports multiple powerful triggering modes including serial bus triggering. There is a low cost option for serial bus decoding of IIC, SPI, UART, CAN, LIN bus types. The models also include History waveform recording, and sequential triggering that enable extended waveform recording and analysis. Other options available include the 25MHz function / arbitrary waveform generator and the 16-channel MSO option both options being field-upgradable. The new digital design also includes a hardware co-processor that delivers measurements quickly and accurately without slowing acquisition and front-panel response.

The features and performance of Teledyne Test Tools new T3DSO2000 series offers outstanding value for money.
