Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger

Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
Solinst Levelogger Junior Edge [JUNIOR] Water Level Logger
from
Rp.15,500,0000
Ex Tax: Rp.15,500,0000
  • Brand: Solinst
  • Part Number: JUNIOR
  • Availability: 4 - 6 WEEKS
  • Last Updated: 22 Jan 2020
 Configure Options

The Levelogger Junior Edge provides an inexpensive alternative for measuring groundwater and surface water levels and temperature. The Levelogger Junior Edge combines a pressure sensor, temperature detector, a datalogger, and 5-year battery (based on a 1-minute sampling rate) in one compact 7/8" x 5.6" (22 mm x 142 mm) stainless steel housing.

The Levelogger Junior Edge records absolute pressure using the same durable Hastelloy® pressure sensor as the Levelogger Edge. The Hastelloy sensor has excellent performance in harsh environments with better temperature compensation and thermal response time, and can withstand 2 times overpressure without permanent damage.

The Levelogger Junior Edge features FRAM memory, with a capacity of 40,000 sets of temperature and water level data points. Readings are linear at a user-defined interval between 0.5 second to 99 hours. Accuracy is 0.1% FS, with lifetime factory calibration.

If greater accuracy, more sampling options, or wider depth ranges are required, the Solinst Levelogger Edge has the functionality to suit your application (see Model 3001 Edge data sheet). For conductivity datalogging, Solinst also offers the LTC Levelogger Edge (see Model 3001 LTC Levelogger Edge data sheet).

Operation
Programming the Levelogger Junior Edge is the same as with the Levelogger Edge. An Optical Reader or PC Interface Cable connects the Levelogger to a laptop or desktop PC. The intuitive Levelogger Software automatically detects the type of Levelogger that is connected. Programming, downloading, data management and export are intuitive tasks. The Real Time View option allows immediate viewing of live water level and temperature readings, independent of the scheduled programming intervals.

The Levelogger Junior Edge outputs temperature and temperature compensated water level readings. Using the Data Wizard in the Levelogger Software, you can barometrically compensation multiple Levelogger Junior Edge files simultaneously, with just one Barologger Edge file.

The Levelogger Junior Edge is compatible with Levelogger Series accessories, including the Solinst Levelogger App and Interface, the DataGrabber data transfer device, SDI-12 Interface Cable, and Solinst Telemetry Systems.

These compact dataloggers are straightforward to deploy. Installation can be with direct read cables, by stainless steel wireline or Kevlar® cord suspension, with the option of using Solinst 2" Locking Well Caps.

Levelogger App & Interface
A smart alternative for programming, data collection, viewing and sharing, is the Levelogger App Interface that uses Bluetooth® wireless technology to connect all Levelogger Series products to your smart device running the Solinst Levelogger App (see Model 3001 Solinst Levelogger App & Interface data sheets).


Features:


  • Low cost
  • Accuracy of 0.1% FS
  • Memory for 40,000 data points
  • Robust Hastelloy pressure sensor
  • Basic and advanced data compensation options


Applications


  • Monitoring water levels in wells and surface water
  • Pump and slug tests
  • Reservoir and stormwater runoff management
  • Watershed and drainage basin monitoring
  • Stream gauging, lake and wetland monitoring
  • Tank level measurement


    What's In The Box:


    • (1) Solinst Levelogger Junior Edge Water Level Logger
    • Required Items:
      • Direct read or suspension wire cables
      • Communications package for programming and downloading data


            Brochure/Datasheet


            Instruction manual


            Note: Prices are not binding , subject to change without prior notice

              Solinst Levelogger Junior Edge 0 Item Selected
            Model
            Product Name
            Price
            Available
            Quantity
            [110241] Water Level & Temperature Logger, 5m ( 15 ft.)
            110241
            Rp.15,500,0000
            1 Availability
            [110242] Water Level & Temperature Logger, 10m ( 30 ft.)
            110242
            Rp.15,500,0000
            1 Availability
