BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator

BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
BK Precision 4054 25 MHz Dual Channel Function/Arbitrary Waveform Generator
from
Rp.20,500,000
Ex Tax: Rp.20,500,000
  • Brand: BK Precision
  • Part Number: 4054
  • Availability: 10 - 14 DAYS WORK
  • Last Updated: 26 Mar 2024
BK Precision BK Precision
Add to Cart
Add to Wish List Compare this Product
Tags: Additel , Digital , Pressure , Calibrators

The BK Precision 4054 25 MHz 2 Ch Function/Arbitrary Waveform Generator is capable of generating stable and precise sine, square, triangle, pulse, and arbitrary waveforms. With easy-to-read color displas and an intuitive user interface with numeric keypad, the BK Precision 4054 Generator offers plenty of features including linear/logarithmic sweep, built-in counter, extensive modulation and triggering capabilities, a continuously variable DC offset, and a high performance 14-bit, 125 MSa/s arbitrary waveform generator.

The main output voltage can be varied from 0 to 10 Vpp into 50 ohms (up to 20 Vpp into open circuit) and the secondary output can be varied from 0 to 3 Vpp into 50 ohms (up to 6 Vpp into open circuit).

Features:

  • 14-bit, 125 MSa/s, 16 k point arbitrary waveform generator
  • Large 3.5-inch LCD color display with waveform preview
  • Linear and logarithmic sweep, Variable DC offset, Adjustable duty cycle
  • AM/DSB-AM/ASK/FM/FSK/PM/PWM modulation functions
  • Two independent channels with individual output On/Off buttons
  • Internal/external triggering, Gate and burst mode
  • 48 built-in predefined arbitrary waveforms, Built-in counter
  • Store/recall up to 10 instrument settings and 10 arbitrary waveforms
  • USB device interface with front panel USB host port, GPIB connectivity with optional USB-to-GPIB adapter (model AK40G)
  • SCPI-compliant command set, Short circuit protection on outputs

What's In The Box:

  • (1) Getting Started manual
  • (1) Full instruction manual on CD
  • (1) AC power cord
  • (1) USB type A-to-type B cable
  • (1) Certificate of calibration

Brochure/Datasheet

Instruction manual
