Name: BK Precision 4011A [4011A-230V] 5MHz Function Generator, 230VAC Line Input
Brand: PT. Indomultimeter Test Instrument
Availability: OutOfStock
Rating: 5 (1 reviews)

BK Precision 4011A [4011A-230V] 5MHz Function Generator, 230VAC Line Input

0 reviews • Write a review

from

Rp.16,165,0000

Ex Tax: Rp.16,165,0000

Brand: BK Precision
Part Number: 4011A-230V
Availability: 4 - 6 WEEKS
Last Updated: 13 Nov 2024

BK Precision

Qty

Add to Cart

Add to Wish List Compare this Product

Tags: Additel , Digital , Pressure , Calibrators

Description

The BK Precision 4011A-220V Function Generator is a versatile signal source that combines several functions into one unit. This model provides the added convenience of a built-in frequency counter. The built-in frequency counter permits more accurate determination of output frequency than is possible with a simple calibrated dial. The coarse and fine tuning controls permit precision settability of the output frequency. The high stability assures that the output frequency does not drift. The heart of the function generator is a Voltage-Controlled Generator (VCG) that produces precision sine, square, or triangle waves over the 0.5 hertz to 5 megahertz range. These waveforms encompass sub-audible, audio, ultrasonic, and RF applications. The continuously variable DC offset allows the output to be injected directly into circuits at the correct bias level. Variable symmetry of the output waveform converts the instrument to a pulse generator capable of generating rectangular waves or pulses, ramp or sawtooth waves, and slewed sine waves. In addition to these features, an external signal can be used to sweep the output frequency or control operating frequency. This feature is useful in situations where an externally controlled frequency is desirable. Due to the versatility, the BK Precision 4011A-220V Function Generator has a vast number of applications in both analog and digital electronics in the engineering, manufacturing, servicing, educational, and hobbyist fields.
