AEMC OX5042B [2150.21] 40 MHz, 2-Channel, 50 MS/s Handscope Portable Oscilloscope with Built-In Multimeter and Power Harmonic Analyzer

Name: AEMC OX5042B [2150.21] 40 MHz, 2-Channel, 50 MS/s Handscope Portable Oscilloscope with Built-In Multimeter and Power Harmonic Analyzer
Brand: AEMC Instruments
Price: 71780000 IDR
Availability: OutOfStock

New

AEMC OX5042B [2150.21] 40 MHz, 2-Channel, 50 MS/s Handscope Portable Oscilloscope with Built-In Multimeter and Power Harmonic Analyzer

0 reviews • Write a review

from

$4.47

Brand: AEMC Instruments
Part Number: 2150.21
Availability: 4 - 6 WEEKS
Last Updated: 04 Oct 2026

AEMC Instruments

Qty

Add to Cart

Add to Wish List Compare this Product

Description

The AEMC Model OX 5042B (2150.21) Handscope is a rugged, handheld test and measurement instrument integrating three essential diagnostic tools into a single compact chassis: a 40 MHz digital storage oscilloscope, an independent dual-channel 8,000-count TRMS digital multimeter with power measurement capabilities, and a 31st-order harmonic analyzer. Built with two completely isolated measurement channels rated to 600 V CAT III, the OX 5042B eliminates common ground reference issues, ground loops, and accidental phase-to-ground shorts. This isolation architecture allows field service technicians and plant engineers to conduct direct differential measurements across live electronic circuits and 3-phase industrial power installations without requiring external differential probes or isolating transformers. Operational efficiency is driven by a vibrant 3.5-inch color TFT-LCD screen with LED backlighting, ensuring high-contrast waveform reproduction and sharp numeric readouts across varied lighting conditions. The streamlined front panel offers direct-access pushbuttons, an integrated interactive multilingual help menu supporting 11 languages, and automatic signal scaling to drastically reduce test setup intervals. The instrument is equipped with 2 MB of onboard non-volatile memory capable of logging up to 2,700 trend points over durations from 5 minutes to 31 days and storing up to 100 BMP graphic screenshots. Data transfer and reporting are managed through an optically isolated USB interface utilizing standard SCPI protocols connected to the included SX-METRO software package. Engineered to endure severe plant and field environments, the OX 5042B features a shockproof elastomer casing with an IP54 ingress protection rating against airborne industrial dust and water spray. Meeting strict international safety requirements per IEC/EN 61010-1 (600 V CAT III / 1000 V CAT II), it ensures comprehensive operator safety during electrical commissioning, routine plant maintenance, and industrial equipment servicing. Powered by six standard rechargeable NiMH AA batteries offering up to 8.5 hours of continuous field autonomy and supported by an intelligent 2.5-hour fast-charge subsystem, this instrument provides an eco-designed, dependable solution for testing mission-critical electro-mechanical and power electronics infrastructure.
